Based on $0.00015/pkt routing overhead & 850k annual autonomous transactions.
Protocol Exclusion Events
Authored traffic demand and exclusion formulas
Read the explanation
The source demand formula multiplies agent count, fanout, and depth times point six. Eight agents, fanout three, and depth four give fifty seven point six, rounded to fifty eight messages per second. Burst mode multiplies by two point eight before rounding, producing one hundred sixty one. At one point four pixels per synthetic message rate the bars span eighty one point two and two hundred twenty five point four. These are authored demand values, not observed gateway measurements or protocol benchmarks. The separate instant ticker instead uses agents times fanout times one point two plus random jitter. The two rate displays therefore follow different rules. At demand fifty eight and capacity twenty five, overflow is thirty three. Drop mode divides thirty three by fifty eight, giving fifty six point nine percent after rounding. The named exponential strategy subtracts half of forty, or twenty, from overflow, then divides thirteen by fifty eight, giving twenty two point four percent. At four pixels per rounded percentage point the bars span two hundred twenty seven point six and eighty nine point six. No actual exponential waiting or request retry occurs. Exclusion triggers above twenty percent dropped or above capacity plus tolerance. Baseline twenty two point four therefore triggers the exclusion label even though fifty eight is below sixty five. The source latency expression adds sixty, demand divided by capacity times four hundred fifty, and depth times eighty. Baseline fifty eight over twenty five at depth four gives fourteen hundred twenty four milliseconds. Burst demand one hundred sixty one gives thirty two hundred seventy eight. At point one five pixels per millisecond the bars span two hundred thirteen point six and four hundred ninety one point seven. Safe concurrency is a separate floor of capacity divided by fanout times one point eight, giving four. The initial caption eight hundred forty is not the computed value. In the offline original the missing D3 dependency stops initialization before controls bind, so these formulas explain source text rather than certify a functioning graph, actual spend forecast, exports, or public traffic.
