AI Microchip Inverse Design Simulator 500× Footprint Reduction

Silicon-on-Insulator (SOI) 2D Wavefield FDTD
Design Architecture
Component Landmark Presets
Laser Source & Frequency
Excitation Wavelength1550 nm
Source Wave Amplitude1.00
AI Topology Optimizer
Interactive Etching & Perturbation

Click or drag on the core simulation viewport to introduce manufacturing defects or custom dielectric scattering pixels in real time.

Silicon (n=3.48)
SiO₂ Cladding (n=1.44)
+E-Field Phase
-E-Field Phase
Core: 2.8 µm × 2.8 µm | Grid: 64×64
Input Port Mode: TE₀ Fund. Simulating Continuous Wave... PML Boundary: Active
Quantitative Optical Telemetry
Insertion Loss
0.14 dB
Target < 0.50 dB
Footprint Reduction
480×
vs. 1.34 mm² human design
Port 1 Transmission
48.6%
Port 2 Transmission
48.4%
Crosstalk Isolation / Extinction
-32.5 dB
Clean optical port mode decoupling
Comparative Scaling Benchmark
Traditional MMI / Bend: 1400 µm × 950 µm (1.33 mm²)
AI Inverse Topology: 2.8 µm × 2.8 µm (0.0078 mm²)
Silicon Real Estate Saved: 99.79% Area Savings
Fabrication Mask & Telemetry Suite

Photonic chip demo: wave stencil versus assigned telemetry

Read the explanation

The canvas evolves a scalar wave on a sixty-four by sixty-four grid. At each interior cell, four neighboring values minus four times the center form a discrete Laplacian. The next field is twice the current field minus the previous field, plus propagation speed squared times that Laplacian, all multiplied by damping. Speed is point four eight divided by an effective index of two point four for silicon and one point four four otherwise. The source injects a sine at the input and advances twice per animation frame. This is a scalar approximation, not a full electromagnetic design validation. Wavelength is used to compute a variable called k, but that variable is never used by the stepping equation; its slider changes the assigned telemetry instead. The displayed performance cards do not integrate power from the wave arrays. They use formulas based on mode, wavelength, preset and iteration count. At the starting splitter wavelength, loss begins at point one four decibels. Each iteration adds a point zero two bonus, capped at point zero eight; a separate point zero eight loss floor is reached after three steps. Port values begin at forty-eight point six and forty-eight point four percent and gain ten times this bonus. After four steps they read forty-nine point four and forty-nine point two. The loss curve uses one hundred pixels per step and fifteen hundred pixels per decibel. These assigned improvements do not prove that a pixel edit improved transmission. A brush changes the matrix but does not recompute these cards. The button labeled gradient iteration visits an interior region and randomly selects about eight percent of cells. A selected cell becomes silicon when its four neighbors sum to at least three, becomes void when they sum to at most one, and otherwise uses another random choice. There is no computed objective derivative, adjoint calculation or model request. Auto refine performs eight such steps; it cannot prove a global optimum. The export labeled GDS two slash SVG actually downloads SVG rectangles, while JSON contains all four thousand ninety-six matrix values and the displayed metrics. Its footprint reduction ratio is always four hundred eighty, even when the visible mode or preset shows another value. The exports preserve the demo configuration; they do not establish physical fabrication readiness.
