AI Data Center Grid & Power Sizing Simulator

Model gigawatt-scale AI compute load, 24-hour supply dispatch, substation interconnect capacity, BESS storage, and clean firm power (SMR & Fusion).

Presets:

1. Compute Workload & Thermal

Accelerator Count 100,000 GPUs Thermal Efficiency (PUE) 1.18 PUE Direct-to-chip / immersion liquid cooling: 1.10–1.20 Workload Profile

2. Grid Interconnect Capacity

Substation Limit 120 MW Regional utility transmission interconnect ceiling Grid Power Tariff ($/MWh) $75 / MWh

3. Behind-The-Meter & Firm Clean

Solar PV Nameplate 100 MW Wind Generation Nameplate 60 MW BESS Battery Storage 160 MWh (40MW/4h) Small Modular Reactor (SMR) 0 MW Commercial Fusion PPA 0 MW

Peak Demand (Cluster + PUE)

141.6MW

1,215 GWh/yr

Grid Deficit / Unserved

0.0MW peak

100.0% Uptime

Clean Energy Share

48.2%

192 gCO2/kWh

Effective Power Cost

$79.4/MWh

$96.5M / yr

24-Hour Power Dispatch & Storage Simulation (Scrub timeline to inspect hourly dispatch)

Grid Interconnect SMR Nuclear Fusion Solar Wind BESS Out Unserved Deficit

Infrastructure & Generation Sizing

IT Compute Direct Load	120.0 MW
Thermal Overhead (PUE)	21.6 MW
Grid Transmission Allocated	120.0 MW
Firm Clean (SMR + Fusion)	0.0 MW
Behind-The-Meter Renewables	160.0 MW nameplate
BESS Max Stored Energy	160 MWh

Reliability & Grid Stress Analysis

Substation Capacity Margin	-21.6 MW (Over)
Curtailed Surplus Energy	148.2 MWh/day
BESS Daily Cycles	0.85 cycles/day
Interconnect Queue Risk	Medium (3-5 yr lead)
Carbon Intensity Score	Grade B+
Levelized Cluster Energy Spend	$0.079 / kWh

● Model running in real-time. Adjust parameters or switch presets.

Solving the AI Power Grid Bottleneck

Why hyperscalers, fusion startups, and utilities are converging on next-generation on-site clean power.

Substation Interconnection Queues

Traditional utility grid interconnects now face 4 to 7 year delays across PJM, ERCOT, and CAISO. High-density AI training clusters exceeding 100 MW require dedicated behind-the-meter generation or transmission upgrades before compute clusters can energize.

SMR Nuclear & Commercial Fusion

Unlike intermittent solar and wind, advanced nuclear fission (SMRs) and magnet-confined fusion provide continuous 24/7/365 firm power without costly gigawatt-hour battery banks, directly matching the continuous 95%+ baseload factor of foundational training models.

PUE & Liquid Cooling Density

As rack power densities surpass 100 kW to 150 kW per rack for next-gen GPU clusters, direct-to-chip liquid cooling and two-phase immersion bring PUE down from 1.45 to <1.15, eliminating dozens of megawatts of parasitic chiller load from the local substation.
