Motorcycle Lean Angle & Slip Limit Physics

Analyze cornering g-forces, Kammsche friction circle saturation, trail braking load migration, and the millimeters between a record apex and a lowside crash.

Jump to Simulator ↓

Telemetry Controls Live Physics

Race Track Scenario Presets

Entry Speed 122 km/h

Corner entry velocity entering apex curvature

Corner Radius (R) 38 m

Geometric track arc curvature at apex

Trail Brake Force 28 %

Front brake lever pressure carried into the turn

Tire Friction Coefficient (μ) 1.62 μ

Racing slick compound grip (MotoGP ~ 1.6–1.8 μ)

Rider Body Offset (Hang-off) 7.2° Offset

Center of mass shift inside the bike center-line

Real-Time Apex Telemetry

Holding balanced trajectory

Stable Cornering

Chassis Lean Angle

59.8°

Combined CG: 67.0°

Lateral Acceleration

1.48 G

Centripetal: 14.5 m/s²

Tire Grip Utilization

91.4%

Margin: 8.6% reserve

Front Contact Patch

4.8 cm²

Shoulder edge load

Chassis Cross-Section & Roll Angle Roll: 59.8°

Tire Traction Friction Circle (Kamm) Combined G Vector

Ready. Adjust entry speed and corner radius to probe limits.

Cornering Physics: Why Riders Hang Off & How Lowsides Happen

When modern MotoGP riders like Izan Guevara or Marc Márquez dive into an apex, centrifugal force pushes outward while tire friction must supply centripetal force inward.

1. Equilibrium Lean Angle

θ_cg = arctan(v² / (g · R))

The total system center of mass must tilt to balance gravity torque against centrifugal moment. Hanging the rider's torso inside reduces chassis lean by 6°–10°, preserving crucial tire edge contact.

2. Kamm's Friction Ellipse

(F_lat / F_lat,max)² + (F_long / F_long,max)² ≤ 1.0

A tire only has 100% total available adhesion. Carrying 40% braking force into maximum lean saturates the front tire contact patch, causing immediate steering head washout.

3. The "Elbow Save" Window

ΔN = F_elbow + F_knee → ΔF_friction > 0

When the front tire loses grip and tucks, pressing the knee puck and elbow slider into the asphalt creates a third pivot point, temporarily reducing vertical load on the tire and allowing it to re-hook.

Why does the Red Bull Ring Turn 4 catch so many riders?

Turn 4 at the Austrian GP drops 7 meters downhill while banking slightly off-camber. The elevation drop unweights the front fork right as riders initiate trail braking, shrinking the contact patch right when maximum grip is needed.

What is the difference between a Lowside and a Highside?

A lowside occurs when front tire lateral demand exceeds grip, washing the front out and sliding the rider down the track. A highside occurs when the rear tire spins up, slides outward, and then violently regains traction, launching the rider over the bike.

Centripetal demand and the illustrative grip circle

Your browser does not support video.

Read the explanation

The source first converts speed from kilometers per hour to meters per second, then uses lateral acceleration equal to speed squared divided by turn radius. Hold radius at forty meters. Start at seventy two kilometers per hour, which is twenty meters per second. The acceleration is ten meters per second squared. The marker begins on that exact quadratic curve. Its horizontal coordinate is input speed and its vertical coordinate is calculated acceleration. This is a steady, level circular motion relation. Increase only speed from seventy two to one hundred eight kilometers per hour. The marker follows the acceleration calculated from each actual speed input. The curve bends upward because speed is squared; it is not a linear growth rule. Radius remains forty meters throughout. This mathematical comparison does not simulate the motorcycle accelerating along a road or establish the grip of a particular tire. Hold at one hundred eight kilometers per hour, or thirty meters per second. Lateral acceleration is twenty two point five meters per second squared. Speed increased by fifty percent, while acceleration demand became two point two five times as large. The marker stops during these numbers. The source then estimates system lean using arctangent of acceleration divided by nine point eight zero six six five. Its tire, contact area and crash thresholds add illustrative assumptions rather than measured physical validation. Return to seventy two kilometers per hour at forty meter radius. Lateral demand is ten divided by nine point eight zero six six five, about one point zero one nine seven two g. Start the trail braking input at zero. Its longitudinal demand is zero, so the resultant equals the lateral component. The horizontal triangle side is lateral demand and the vertical side is braking demand. All side lengths and the reference bars use one hundred eighty pixels per g. Increase trail braking percentage from zero to one hundred. The source maps that percentage linearly to zero point nine five g at full input. The vertical endpoint rises, and the diagonal follows the square root of lateral demand squared plus braking demand squared. Lateral demand stays fixed. The growing comparison bar uses the length of this same demand vector. The friction coefficient is held at the source value one point six two as a model reference. Hold trail braking at one hundred percent. The braking side is point nine five g and the resultant is about one point three nine three six seven g. Dividing by one point six two gives about eighty six point zero three percent modeled utilization. The triangle and bars remain stationary while those values are read. The source braking conversion and friction coefficient are assumptions, not calibrated tire or road predictions. The picture explains the declared demand equation. Keep seventy two kilometers per hour and forty meter radius. The computed system lean is about forty five point five five nine degrees. The source rider offset approximation subtracts hang off degrees from that system lean and clamps the result at zero. Start offset at zero: chassis lean equals system lean. The cyan bar shows the invariant system value and the yellow bar shows the computed chassis value. Both share seven pixels per degree. Increase only rider offset from zero to eight degrees. The yellow bar shortens by exactly the input offset times the shared pixel scale. System lean remains fixed. This is the source subtraction approximation, not a solved distribution of rider and motorcycle masses. The numerical comparison shows what the formula does; it does not validate a posture, a tire setup or a riding maneuver. Hold rider offset at eight degrees. System lean remains about forty five point five five nine degrees, and the source chassis approximation is about thirty seven point five five nine degrees. The bars stop while the numbers are spoken. Run on this page changes trail braking percentage over two point five seconds while speed and radius stay fixed. It does not produce a spatial trajectory. Original presets, all five sliders, reset, Run and the complete fifteen row C S V export remain available above the video.
