Apex Overtake Telemetry Lab

Simulate the physics of racing overtakes. Benchmark inside divebombs, switchbacks, and trail-braking deltas against defensive lines with frame-by-frame corner telemetry.

TIME0.00s DIST0m
GAP+0.12s STATUSSide-by-Side
Corner Outcome: Attacker successfully takes the inside line into Turn 3!
Exit Lead: +0.24s

Speed Profiles (km/h) #37 vs #1

Lateral G & Lean Angle Max: 1.48G (64°)

Ready. Scrub timeline or press play to evaluate overtake physics.

1. The Divebomb Physics

Braking 20 meters deeper than standard claims track position at turn-in, but severely compresses the deceleration envelope. The rider must square off the corner or risk running wide on exit.

2. The Switchback Defense

When an attacker plunges up the inside, the defending racer delays throttle application, cuts behind the attacker's compromised apex, and uses superior launch traction down the exit straight.

3. Trail-Braking Thresholds

Combined braking and cornering demands adhere to Kamm's friction circle (μ). As lean angle approaches 64°, available longitudinal deceleration drops to under 0.25G before front-end tuck.
