Climbing Fall Physics UIAA-101

Dynamic rope stretch, fall factor & anchor load mechanics

Presets:

Physics Viewport (Matter.js)

Anchor Climber Belayer
Click wall to place custom protection anchor

Real-time Telemetry & Telemetrics SAFE_WITHIN_LIMITS

Fall Factor (f = ΔL / L)
0.40
UIAA Max Limit: 2.0
Peak Anchor Load
4.82 kN
Anchor rating ~ 12 kN
Dynamic Rope Stretch
2.15 m
Elastic elongation
Belayer Force
2.89 kN
Force transferred
Peak Deceleration
Climber body acceleration
6.56 g

Physics Simulation Parameters

8.0 m
20.0 m
75 kg
25.0 kN
0.50 m
60°

Dynamic Force-Time Curve (D3.js)

Impact Dynamics (0 to 1.5s)

UIAA Fall Factor Guidance

The severity of a climbing fall depends primarily on the Fall Factor (f = ΔL / L), defined as total drop distance divided by active rope length. A 10m fall on 5m of rope (f = 2.0) creates far higher peak anchor forces than a 10m fall on 50m of rope (f = 0.2).
