ELECTROMAGNETIC FLUX & ROTOR POLAR FIELD
3,600 RPM | Rotor Angle: 0°
0g TARGET
Rare Earth Metals
0.0 kg
100% eliminated
-25% TARGET
Drive Unit Mass
66.0 kg
-25.0% vs 88kg
-18% TARGET
Packaging Volume
34.85 L
-18.0% vs 42.5L
<10s CYCLE
Automated Mfg Time
9.4 s
Sub-10s automated
SOURCE GROUNDING & ENGINEERING CONTEXT
“The Cybercab motor uses no rare earth metals, but maintains the same range! This was extremely hard to achieve.” — Elon Musk
“The Cybercab drive unit features a simplified bar-wound stator and lubrication system, plus an overall architecture that enables fully automated, sub-10-second cycle times. It is 18% smaller, 25% lighter and more efficient than other top performing electric vehicle drive units.” — Sawyer Merritt
“The Cybercab drive unit features a simplified bar-wound stator and lubrication system, plus an overall architecture that enables fully automated, sub-10-second cycle times. It is 18% smaller, 25% lighter and more efficient than other top performing electric vehicle drive units.” — Sawyer Merritt
ROTOR ELECTROMAGNETIC TOPOLOGY
ACTIVE SELECTION
Cybercab SynRM
Ferrite-Assisted / 0g Rare Earth
Conventional PM
NdFeB / Dysprosium (1.8kg RE)
Pure SynRM
Flux Barrier Only (No Magnets)
Induction Motor
Copper/Al Rotor Squirrel Cage
STATOR & HAIRPIN CONDUCTOR DESIGN
AUTOMATED SUB-10-SECOND ASSEMBLY STAGES
Total: 9.4s
1. Stator High-Speed Lamination Stacking
2.1s
2. Automated Hairpin Pin-Bending & Insertion
3.2s
3. Robotic Twist & Simultaneous Laser Welding
2.6s
4. Integrated Lubrication & Rotor Drop
1.5s
SPECIFICATION COMPARISON & TEARDOWN
| METRIC | BASELINE EV | CYBERCAB DRIVE UNIT | DELTA |
|---|---|---|---|
| Rotor Architecture | NdFeB Permanent Magnet | Ferrite-Assisted Reluctance | 0g Rare Earth |
| Total DU Mass | 88.0 kg | 66.0 kg | -25.0% |
| Package Volume | 42.5 L | 34.85 L | -18.0% |
| Peak Efficiency | 96.8% | 97.2% | +0.4% |
| Nd / Dy Content | 1.80 kg | 0.00 kg | -100% |
| Mfg Cycle Time | 48.0 s | 9.4 s | -80.4% |
