DDR5 Timing & Latency Architecture Workbench

TechRadar PC RAM Analyzer

Timing Configuration

Dual 32-bit Subch.
STANDARD PRESETS:
6000 MT/s
30 cycles
36 cycles
36 cycles
76 cycles
Corsair DDR5-6000 CL30 provides 10.00 ns absolute first-word latency, hitting the 1:1 memory controller sweet spot.

Physical Nanosecond Latency & Bus Telemetry

tCK: 0.333 ns
First Word Latency
10.00 ns
tCL * 2000 / MTps
Row Cycle Time (tRC)
37.33 ns
112 cycles
Peak Bandwidth
48.0 GB/s
Dual 32-bit (64-bit)
Workload Throughput
41.28 GB/s
Gaming & Streaming
DDR5 Command & Data Burst Waveform (BL16 Subchannel A/B) Hover/Drag to Inspect Cycles
Workload Access Profile Simulator Simulate real CPU memory subsystem access penalties
ESTIMATED ACCESS LATENCY
58.4 ns
FRAME-TIME VARIANCE
±1.4 ms (Smooth)
BUS EFFICIENCY
86.0% (Dual Subch.)
Profile Kit Transfer Speed Primary Timings True Latency (tCL) Row Cycle (tRC) Peak Bandwidth
Corsair Vengeance DDR5-6000 6000 MT/s 30-36-36-76 10.00 ns 37.33 ns 48.0 GB/s
Corsair Vengeance DDR5-6000 6000 MT/s 36-38-38-80 12.00 ns 39.33 ns 48.0 GB/s
JEDEC DDR5-4800 Baseline 4800 MT/s 40-40-40-77 16.67 ns 48.75 ns 38.4 GB/s
Enthusiast DDR5-6400 6400 MT/s 32-39-39-102 10.00 ns 44.06 ns 51.2 GB/s
Legacy DDR4-3200 3200 MT/s 16-18-18-38 10.00 ns 35.00 ns 25.6 GB/s

Trace DDR timing cycles and assigned bandwidth efficiency

Read the explanation

The written first-word latency equals CAS cycles times two thousand divided by transfer rate. At six thousand mega-transfers per second, thirty cycles gives ten nanoseconds; thirty-six gives twelve. Both bars use thirty-five pixels per nanosecond. Double-data-rate transfer rate is twice the clock frequency, which supplies the factor two thousand. This timing formula does not include a complete processor-to-memory access path or prove a gaming performance result. The source multiplies six thousand mega-transfers per second by two thirty-two-bit subchannels, divides by eight bits per byte and one thousand, and obtains forty-eight decimal gigabytes per second of peak bandwidth. Its mixed gaming-and-streaming mode assigns eighty-six percent efficiency, giving forty-one point two eight. Both bars use ten pixels per gigabyte per second. Efficiency and frametime are preset assumptions, not measured workloads or hardware tuning recommendations. Row cycle combines row-active seventy-six cycles and precharge thirty-six, for one hundred twelve cycles. At the default transfer rate, multiplying by two thousand divided by six thousand gives about thirty-seven point three three nanoseconds. First-word CAS timing is ten. Both bars use twelve pixels per nanosecond, and the row bar uses the exact unrounded calculation. These terms represent different timing constraints. Changing tRCD affects the drawn schedule but the source does not add it to either of these two exported formulas.
