Race Telemetry & Engine Diagnostics Lab

Simulate high-frequency Formula 1 Power Unit telemetry, pinpoint sudden sensor & mechanical failures, and track seasonal component allocations with FIA grid penalty verification.

PU Status DTC ACTIVE
Oil Pressure 1.4 BAR
Grid Drop 0 PLACES
87
O. Bearman
Haas F1 Team • Ferrari 066/12 PU
● ENGINE SHUTDOWN
Lap Window: Sector 2 Castle Section T+ 32.4s / 60.0s
Engine RPM
0 RPM
Oil Pressure
1.4 BAR
Coolant Temp
126 °C
MGU-K Output
0.0 kW
ECU Diagnostics & Event Stream
28.4s [DTC-P0524] Engine Oil Pressure Below Critical Safety Minimum (< 2.0 bar)
29.1s [DTC-P0304] Cylinder 4 Continuous Pre-Ignition Knock Detected (Severity: 9.8g)
30.2s [DTC-U0100] Hydraulic Protection Interlock Failsafe Activated
31.0s [DTC-P1604] ECU Automatic Engine Kill Initiated ("My engine broke")

FIA Power Unit Component Allocation & Penalty Calculator

Track active pool component usage against the FIA annual sporting limits. Exceeding any allocation incurs strict starting grid penalties.

ICE (Engine)
4
Allowed: 4
Turbo (TC)
4
Allowed: 4
MGU-H
4
Allowed: 4
MGU-K
4
Allowed: 4
Energy Store
2
Allowed: 2
Electronics
2
Allowed: 2
✓ ALL POWER UNIT ELEMENTS WITHIN SEASON ALLOCATION
Penalty: 0 Grid Positions (Eligible for Qualifying Result)

1. Hydraulic & Scavenge Failures

In modern Formula 1 V6 turbocharged hybrid units, the scavenge oil pump operates under extreme G-forces. If cavitation or pump seizure occurs, line pressure plummets below 2.0 bar within 400 milliseconds, starving journal bearings and causing immediate piston seizure.

2. Failsafe Electronic Shutdown

Telemetry ECUs (Standard Electronic Control Units) run threshold surveillance. When knock sensors record pre-ignition in excess of 8G or oil starvation is confirmed, the safety map cuts spark and high-voltage ERS deployment to prevent catastrophic block perforation.

3. FIA Grid Penalty Rules

Under FIA Formula 1 Sporting Regulations Article 28, introducing a 5th ICE, TC, MGU-H, or MGU-K results in a 10-place grid drop for the first infraction, and 5 places for subsequent elements. Cumulative penalties exceeding 15 places require starting from the rear of the grid.
