F-15 EAGLE SIM

Engine Surge & High-Speed RTO Simulator

THROTTLE POSITION 100%
INTAKE AIRFLOW DISTORTION 0%
PRESET SCENARIOS
0.0s
TAKEOFF ROLL NORMAL
Airspeed 142 KTS V1: 135 KTS
Runway Remaining 6200 FT Total: 10000 FT
L Engine Thrust 29000 LBF N1/N2: 100%
R Engine Thrust 29000 LBF N1/N2: 100%
Left EGT Peak 920 °C Limit: 900 °C
Brake Heat Cap 22% Max 100%

Aerodynamic Principle: Compressor stall occurs when airflow over internal turbine blades separates due to high distortion or pressure mismatch. Left surge reduces thrust instantly, generating extreme asymmetric yaw torque towards the dead engine.

State: Speed 142kt | L-Thrust 29000lbf | Brake Heat 22%
