FMVSS 108 Photometric Safety Limits
| Test Point Zone | Angle Range | Max Allowed Lux | Calculated Lux | Status |
|---|---|---|---|---|
| 0.5° U - 1.5° L (Oncoming Glare) | 0.5° Up, 1.5° Left | 0.80 lux | -- | -- |
| 1.0° U - 1.5° R (Sign Glare) | 1.0° Up, 1.5° Right | 1.20 lux | -- | -- |
| 0.5° D - 1.5° R (Pavement Illuminance) | 0.5° Down, 1.5° Right | > 15.0 lux (Min) | -- | -- |
Current configuration generates excessively bright low-beam glare exceeding federal photometric ceilings.
Fleet Defect Distribution (20,000 Vehicles)
Total Recalled Units
20,000
Non-Compliant Defect Rate
72.4%
Estimated Glare Vehicles
14,480
Compliance Target Margin
-0.64 lux
