01. Hardware Selection
02. Load Physics Inputs
45 lbs
12 in
2 anchors
1/4" Toggle Bolt
DRAG: Orbit
PINCH/SCROLL: Zoom
3D WebGL renderer initializing...
THICKNESS / LENGTH
3.00 in (76.2mm)
MAJOR DIAMETER
0.250 in (6.35mm)
THREAD PITCH / TPI
20 TPI (UNC)
03. Imperial vs Metric Thread Profile Matcher Direct Pitch Comparison
Imperial Profile
1/4"-20 UNC
Standard heavy drywall toggle thread. 20 Threads Per Inch. Coarse pitch ideal for high clamping force in hollow walls.
Metric Equivalent
M6 x 1.0mm
Nearest metric ISO bolt match (6.0mm outer diameter vs 6.35mm). Do NOT cross-thread UNC and Metric nuts!
Safety Factor Rating
2.85x SAFE
Structural Mounting Verified
The selected toggle bolt anchor configuration easily distributes combined shear & leverage pull-out force on 1/2" drywall.
ACTUAL SHEAR / ANCHOR
22.5 lbs
CALCULATED PULLOUT
13.5 lbs
RATED SUBSTRATE CAP.
70.0 lbs
SUGGESTED DRIVE
#2 Phillips / Flat
04. Grown-Up Tool Gap
3 Gaps FoundCheck items currently in your home toolbox to generate an instant essential hardware gap report:
3 Recommended Tool Additions
