Air-Supported Construction Dome Engineering Workbench

Internal Gauge Pressure 300 Pa

Wind Velocity 75 km/h

Site & Geometry

Span Width 120 m

Dome Apex Height 35 m

Membrane Tensile Rating 45 kN/m

Pneumatics & Wind Forces

Internal Overpressure 300 Pa

Ambient Wind Velocity 75 km/h

Airlock Throughput 12,000 m³/h

Dynamic Diagnostics

Hoop Stress

31.5 kN/m

Anchor Line Load

18.4 kN

Blower Power Req.

42.5 kW

Dust Containment

98.6%

Actions & Export

Calculated Proof Verification

Status STRUCTURALLY_STABLE

Safety Factor 1.43

Hoop Stress 31.5 kN/m

Anchor Load 18.4 kN

Blower Power 42.5 kW

Containment Rate 98.6%
