Cleanroom Assembly Flow (5-Stage Precision Funnel)
Daily Target: ~15,000 | Current Output: 350
STAGE 01
5-Axis Titanium CNC Milling
Cycle:840s
Step Yield:78%
STAGE 02
Ultra Silicon CoWoS Packaging
Cycle:360s
Step Yield:85%
STAGE 03
Tandem Display OLED Lamination
Cycle:480s
Step Yield:68%
STAGE 04 (CHOKEPOINT)
Quad-Prism Optical Active Align
Cycle:920s
Step Yield:42%
STAGE 05
Vacuum Acoustic Sealing & Test
Cycle:310s
Step Yield:92%
Finished Daily Run
350
Nikkei Reported Baseline
Cumulative Yield
17.4%
Compound Pipeline Pass
Scrap Loss / Unit
$1,142
Component Write-offs
Pipeline Bottleneck
Optical Align
42% Step Yield
Global Flagship Allocation
525 Stores
DAILY UNITS PER STORE
Target: 28/day
0.67
Fewer than 1 unit/store per day. Severe lottery allocation.
LAUNCH BACKORDER SLIP
1.8M Pool
14.2 wks
Preorders slip into early December delivery windows.
16-Week Production Ramp & Delivery Curve
Learning Rate Yield Compounding
Estimated recovery to 8,500 units/day by Week 8 as Active Optical Alignment calibrators are retrofitted.
Flagship Retail Rationing Matrix
Tier 1 Metro Hubs
