Live Kinematic Overlay Viewport
Frame: 0 / 300 (0.00s)
TRACKED JOINT FOCUS
SMOOTHING FILTER
0.35
PLAYBACK SPEED
1.0x
CONFIDENCE THRESHOLD
0.70
Kinematic Telemetry & Velocity Profile
Joint Angle
142.5°
Angular Velocity
88.4°/s
CoM Height (Y)
0.52 m
Movement Cadence
62 bpm
Biomechanics Diagnostic & Science Communication
- Vector Coordinate Mapping: Converts pixel 2D landmarks into calibrated spatial vectors for localized angular dynamic calculation.
- Angular Velocity Derivation: Evaluated via central difference formula:
ω = (θ[t+Δt] - θ[t-Δt]) / (2·Δt)filtered with exponentially weighted moving average. - Center of Mass (CoM): Estimated using segmental mass fractions (Winter biomechanics model) across key torso, hip, and limb vertices.
- Forensic Motion Note: Optical noise is distinguished from micro-gesture motion cadence through dynamic confidence thresholding.
