SF Marina Waterfront Housing Zoning & Shadow/View Analyzer

Parcel Site: SF Marina Waterfront (145,000 sq ft)

Solar Elevation: 34.0° | Azimuth: 225.0°

Camera Target: Marina Green Park

Redevelopment Presets

Solar & Seasonal Controls

Seasonal Equinox / Solstice

Solar Time of Day 15:00 (3:00 PM)

Tower Massing & Podium

Tower 1 Stories 22 Stories

Tower 2 Stories 18 Stories

Podium Stories 4 Stories

View Corridor Analysis

Public Line-of-Sight Point

Real-Time Zoning Metrics

            Total Housing Units
            680
            Units @ 850 sqft avg


Affordable Yield 136 20% Below Market Rate

Floor Area Ratio (FAR) 8.4 Site FAR Index

Max Shadow Length 482.5 Feet from base

Public Realm Shadow 14.2% Marina Green Overlap

Bay View Blocked 28.5% Sightline Obscuration

Export Brief & State

Total Units: 680

Affordable Units: 136

FAR: 8.4

Max Shadow: 482.5 ft

Park Shadow %: 14.2%

Bay View Blocked: 28.5%
