MCP: Model Context Protocol Explainer

Hub & Spoke Topology — drag to orbit, scroll to zoom, click a server

drag: rotate · wheel: zoom · click node: run request

MCP Servers

JSON-RPC Message Flow

// click a server (or RUN) to trace a
// full MCP request/response cycle

Host

The application the user runs — Claude Code, Claude Desktop, an IDE. It owns the LLM loop, enforces permissions, and decides which servers to attach.

Client

The connector inside the host. One client per server, maintaining a stateful 1:1 session. It speaks JSON-RPC 2.0 over stdio (local) or Streamable HTTP (remote).

Server

A lightweight capability wrapper. It exposes a database, a browser, a filesystem, or an API as standard primitives — write it once, and every MCP host can use it.

Tools

Model-controlled actions
Declared with a JSON Schema
Invoked via tools/call
e.g. run_query, deploy_app

Resources

App-controlled read-only data
Addressed by URI
Read via resources/read
e.g. file://schema.sql, logs

Prompts

User-controlled templates
Reusable, parameterized
Fetched via prompts/get
e.g. /review-pr, /summarize

Why it matters

The N x M problem: before MCP, connecting N apps to M tools needed N x M custom integrations. A shared protocol collapses that to N + M — each side implements MCP once.

Lifecycle: every session starts with an initialize handshake where client and server negotiate protocol version and exchange capability flags before any tool runs.

Discovery is dynamic: the agent calls tools/list at runtime, so servers can add or change tools without redeploying the host.

Security rule of thumb: the host mediates everything — tool calls should be permission-gated, and results are untrusted input (watch for prompt injection in returned data).

Transports & the wire format

stdio: the host launches the server as a child process and pipes newline-delimited JSON-RPC over stdin/stdout. Zero network setup, ideal for local tools like filesystem or git servers.

Streamable HTTP: a single endpoint accepts POSTed JSON-RPC messages and can stream responses back via Server-Sent Events. This is how remote/hosted MCP servers work, typically secured with OAuth 2.1.

Everything is JSON-RPC 2.0: three message kinds only — requests (have an id, expect a reply), responses (carry result or error for that id), and notifications (fire-and-forget, e.g. notifications/tools/list_changed).

Sampling — the reverse direction: a server can ask the client's LLM to complete text via sampling/createMessage, letting servers embed intelligence without shipping their own API keys.

MODEL CONTEXT PROTOCOL // AGENT WIRING SCHEMATIC
