5G NR RF Active

Mobile Data Bandwidth vs Expiry Simulator

Tower Load 12%
Packet Latency 18 ms
RF Spectrum Util 15 / 100 Mbps
Active Policy Rollover
Cellular Cell Tower & RF Resource Block Visualization
Click device to burst packets
Data Policy Accounting Rules
Active Subscribers 25 Users
Tower Bandwidth Capacity 100 Mbps
Background Traffic Intensity Medium
User Balance Per Device 5000 MB
Instantaneous RF Throughput vs Latency Peak: 0 Mbps
Subscriber Balance Decay vs Expiry Ledger Total Volume: 125 GB
Technical Network Engineering Reality

Physics & Radio Frequency Channels (Mbps)

Cellular base stations use time-frequency Resource Blocks (RBs) on shared radio bands. Tower congestion occurs strictly when simultaneous user bandwidth demands exceed the tower's instantaneous megabits-per-second (Mbps) capacity. Latency spikes and queues form regardless of how much total volume users have in their accounts.

Billing Ledgers & Account Balances (MB/GB)

Data balances (MB/GB) are purely numerical entries in a database ledger. Stored data volume consumes zero radio spectrum, zero tower power, and zero channel capacity when idle. Mobile data expiry rules are business billing structures rather than physical cellular radio constraints.
