Model nanoimprinted optical metasurfaces, sub-micron grating coupling losses, photonic link budgets, and rack-scale electrical vs optical power savings for next-gen AI clusters.
Comparing Co-Packaged Optics against electrical DAC cables at full switch saturation.
Traditional optical couplers in data centers rely on sub-micron active alignment or precision etched silicon grooves, bottlenecking throughput. High-precision roll-to-plate nanoimprint lithography stamps optical gratings and diffractive metasurfaces over large glass or polymer panels at wafer scale, dropping per-port packaging costs while maintaining >70% coupling efficiency.
At 100G and 200G per lane (PAM4), direct-attach electrical copper (DAC) cables cannot exceed 1 to 2 meters without massive retimer DSP power penalties (>25 pJ/bit). Moving the optical engine directly onto the ASIC substrate (Co-Packaged Optics) shaves off up to 80% of I/O power and clears physical cable congestion.
For mission-critical AI training clusters, an optical link margin below 2.0 dB risks catastrophic dropped gradient synchronizations. This simulator continuously verifies launch power against grating efficiency, fiber attenuation, connector mating, and detector sensitivity to ensure robust error-free transmission.
