Raycast Geometric Sightline Analysis

In municipal architecture and security design, claiming a monumental structure functions as a "military complex" or defensible perimeter requires rigorous geometric visibility validation. Occlusion shadows occur wherever stone mass, arch piers, or urban facades block electromagnetic and direct line-of-sight (LOS) sensors.

This engine computes exact 2D visibility polygons by casting intersection rays against all polygon vertices, calculating shadow penumbras, and simulating autonomous UAV patrol circuits along defined orbital radii.

Critical Perimeter Metrics & Constraints

• Elevation Advantages: Elevated platforms (such as a 45m civic arch crown) compress ground blind spots but introduce steep downward dead-zones at the structure's base.
• Cross-Overwatch: Unilateral sniper posts leave acute approach corridors vulnerable; multi-point triangulation is required to counter urban clutter.
• Drone Loiter Integration: Autonomous perimeter drones fill building shadow zones but consume power exponentially when hovering in crosswinds.
