Galvanic Isolation Boundary & Current Flow Schematic
24VDC ↔ 5VDC ISOLATED
Calculated Series Resistor
1520 Ω
(V_in - V_f) / I_target
Nearest E24 Standard
1500 Ω
Standard 5% Component
Actual Forward Current
15.2 mA
Diode I_f @ Standard R
Resistor Power Dissipation
346.56 mW
Exceeds 1/4W (250mW)!
Recommended Resistor Rating
1/2W (0.5W) minimum
Thermal safety headroom
Propagation Delay & Logic
18 μs
Active-Low Inverted
DUAL-CHANNEL LOGIC OSCILLOSCOPE (CH1: 24V PLC OUT [ORANGE] | CH2: 5V MCU PIN [TEAL])
10 Hz Auto-Pulse
Rockwell Studio 5000 / CCW Ladder Rung
XIC(Run_PB) OTE(Opto_Out_0);
Arduino / VEX V5 Embedded C++ Firmware
const int OPTO_PIN = 2;
void setup() { pinMode(OPTO_PIN, INPUT_PULLUP); }
