Vehicle Dynamics & Collision Reconstruction

Road Safety Kinematics & Stopping Distance Simulator

Directly explore how speed, perception-reaction lag, tire-road surface friction, and vehicle mass govern stopping envelopes and crash impact severity. Every extra mile per hour remains as squared kinetic energy right up to the final meters.

Kinematics Visualization

Ready. Adjust parameters or click Run Simulation.
Export Data
Thinking Distance 32.2 m Time: 1.20 s @ 60 mph
Braking Distance 50.8 m Peak decel: -7.06 m/s² (0.72 g)
Total Required Distance 83.0 m Safe margin: -8.0 m
Impact Velocity 28.4 mph 133 kJ Dissipated
CRITICAL COLLISION OCCURS Vehicle cannot stop before reaching the 75m hazard. It strikes at 28.4 mph with 133 kJ of residual kinetic energy.

Velocity Profile Over Distance: v(x) Non-linear drop: remaining speed stays high until final moments

1. The Squared Velocity Multiplier

Kinetic energy scales with the square of speed ($E_k = \frac{1}{2}mv^2$). When driving at 60 mph instead of 50 mph, speed is only 20% higher, but kinetic energy increases by 44%. That entire surplus energy must be absorbed by tire-road shear friction or crushing structural impact.

2. The Deceptive Final Metres

Because $v(x) = \sqrt{v_0^2 - 2ax}$, braking decelerates velocity slowest at high speed. A vehicle traveling at 60 mph that brakes hard to stop right at 83 meters will still be traveling at over 40 mph halfway through its braking zone. Small distance deficits produce catastrophic impact speeds.

3. Reaction Horizon

At 60 mph (88 ft/s or 26.8 m/s), a driver covers nearly 27 meters every second before their foot touches the brake pedal. In low-visibility or distracted states (cell phone, fatigue, bends), thinking distance alone often exceeds the total sightline distance.
