Router Hardware Back Panel
Model: Tri-Band Gaming & Fiber Gateway
DUAL-BAND MULTI-GIG FIBER ACCESS 2.5G
2.5 Gbps Multi-Gig Link
1 Gbps Gigabit Link
Bottleneck / Under-provisioned
Connected Devices & Port Assignments
Direct Device Patching
Select the router Ethernet port for each device below. Watch the hardware panel and live telemetry react immediately.
Port Allocation Telemetry
● LIVE SYNC
Total Allocated Bandwidth
2,250 Mbps
Across all active LAN/WAN ports
Optimal Port Utilization
92.5%
Capacity matched efficiently
Bottleneck Detected
False (0)
Zero port starvation
WAN Uplink Throughput
2.0 / 2.5G
ONT Fiber to 2.5G WAN
All high-throughput devices are correctly mapped to high-speed ports with zero bandwidth starvation.
Engadget Port Identification Guide
- WAN (Yellow/Blue Port): Connects directly to your Fiber ONT or Cable Modem. Never connect client computers or smart TVs here.
- 2.5G Multi-Gig LAN: Reserved for PC gaming rigs with 2.5GbE cards or high-throughput multi-user NAS appliances.
- Gigabit LAN 1-3: Ideal for 4K streaming TVs, game consoles, printers, and smart home bridges where 1,000 Mbps exceeds demand.
Active Cabling Configuration Export
Ready
