RugOne Detachable Action Cam Rig & Field Telemetry Lab

CHASSIS DOCK & RIG MOUNT SCHEMATIC

detached_tethered

DRAG THE ACTION CAM POD TO UNDOCK / SNAP TO MOUNT

DEPLOYMENT RIG SELECTOR DIVE TRAY 10M

Water Submersion Depth 5.5 m

Ambient Field Temp 18 °C

Video Capture Profile 4K60 HDR

Link Architecture Wi-Fi Direct P2P

FIELD TELEMETRY & POWER ENGINE

DUAL BATTERY ENGAGED

VIEWFINDER MONITOR • 5.8GHz 60 FPS • LIVE

TX LINK ACTIVE

EIS: ROCKSTEADY 3.0

System Runtime

            118
            mins

Cam: 1,250mAh | Phone: 10,000mAh

P2P Stream Latency

            38
            ms

Wi-Fi 6 Direct P2P (866 Mbps link)

Storage Bitrate

100 Mbps

H.265 / HEVC 10-Bit

Thermal Margin

14.2 °C to Throttling

Aviation Aluminum Shell Dissipation

RIG BILL OF MATERIALS & RATINGS submerged_safe

Active Mount:	10m Submersible Dive Tray w/ Dual Lanyard
Combined Mass:	392 g (Cam 82g + Rig 310g)
Waterproofing Rating:	IP68 / 5ATM Sealed (Depth: 5.5m / 10m Max)
Shock Absorption:	MIL-STD-810H Rated / 1.8m Drop Resistance
Dock Connection:	detached_tethered

STATUS: Telemetry stable. 5.5m depth safely inside 10m dive limit.
