Galvanic Potential ($E_{cell}$)-0.880 V vs Ag/AgCl
Anode Tool:
Click on steel hull canvas to deploy sacrificial anode
Historical Shipwreck Profile
1941 Battleship
Steel Hull + Brass
Coral Reef Freighter
Iron Hull + Sheathing
1912 Deep Liner
Cold Deep Water
Electrolyte Parameters
Salinity (PSU)35 PSU
Dissolved Oxygen ($O_2$)6.5 mg/L
Water Temperature15 °C
Current Velocity0.5 m/s
Protection Telemetry
Current Density
128.4 mA/m²
Target: 80 - 150 mA/m²
Anode Count / Mass
4 / 48.0 kg
Mass Loss: 1.2 kg/yr
Anode Lifespan
18.4 Years
Until Complete Consumption
Corrosion Rate
0.02 mm/yr
Efficiency: 94.2%
Microstate Particle Legend
Electron ($e^-$) Drift
Iron Ion ($Fe^{2+}$)
Hydroxyl ($OH^-$)
Rust Precipitate
Preservation Chemistry
Submerged iron oxidizes via cathodic oxygen reduction:
Fe → Fe²⁺ + 2e⁻ (Anodic)
O₂ + 2H₂O + 4e⁻ → 4OH⁻ (Cathodic)
Attaching sacrificial anodes with lower electrochemical potential ($E^0$) forces the anode to oxidize preferentially, supplying electrons to cathodic protection boundaries on the ship hull.
Shipwreck Cathodic Preservation Analysis Report
Generated telemetry analysis log for cathodic protection efficiency, galvanic microstate dynamics, and anode consumption curves.
