Steel Iron-Carbon Metallurgy & Stress-Strain Simulator

1. Metallurgy & Heat Treatment 99.55% Fe

Carbon Content (% C) 0.45%

Cooling / Heat Treatment Regime

Microstructural Equilibrium Phases

Alpha Ferrite (α-Fe) 58.3%

Pearlite (Lamellar) 41.7%

Fe3C Cementite 0.0%

Martensite (BCT) 0.0%

Metallographic View (500x) Equiaxed Ferrite + Pearlite

Elastic Modulus

205 GPa

Hardness

185 HB

Yield Point (σy)

382 MPa

Ultimate Strength

615 MPa

2. Mechanical Testing & Stress Analysis Real-time Constitutive Engine

Tensile Test Specimen Elastic State

Applied Crosshead Pull Strain (ε) 0.00 %

Stress-Strain Curve 0 MPa

3. Architectural Structural Beam Load Test (W12x26 I-Beam) Safety Margin: Safe

Central Column Load 120 kN

Structural Mode

Ductile Deflection
