UV Surface Print Clearance & Curing Planner

Tracking: Dynamic Conform Substrate: Curved Shell
Safe Standoff (1.5 - 3.5mm)
Throw Limit Warn (> 3.5mm)
Collision Hazard (< 1.0mm)
UV Curing Irradiance Cone
Clearance Status
compliant
No collision risk
Min Standoff (mm)
1.85
Safe gap > 1.0mm
Max Standoff (mm)
3.42
Within 4.5mm limit
Scatter Risk
4.2%
Crisp drop dotting
UV Cure Range
185 - 240
mJ/cm² (Fully cured)
Est. Pass Time
48 s
120 mm/s traverse

Substrate & Geometry Preset

14.5 mm
8.0 mm

Toolpath & UV Parameters

2.0 mm
4.5 mm
120 mm/s

Clearance & Collision Verification COMPLIANT

Calculated toolpath clearance envelope across 256 surface sample coordinates. Dynamic Z-conforming head eliminates printhead crashes while sustaining crisp dot dispersion.

G-Code Height Compensation & Telemetry Log

// Dynamic Height Offset Table G0 X-80.0 Y-40.0 Z16.50 ; Initial clearance G1 X-60.0 Y-40.0 Z16.50 F7200 G1 X-40.0 Y-20.0 Z17.80 F7200 ; Contour bevel entry G1 X-00.0 Y-00.0 Z18.50 F7200 ; Substrate peak UV_LAMP_POWER_SET 85% ; Normal dose achieved
