Interactive Stick Test
MANUAL DRAG
Automated Trajectory Probe
12-BIT RAW (X, Y)
2048, 2048
FINAL SHAPED OUTPUT
0.00, 0.00
RADIAL DEFLECTION
0.0 %
DEADZONE STATE
IN CENTER (0.0)
Why 12-Bit matters: Standard Xbox/PS4 controllers use 8-bit (256 steps per axis). Flydigi Vader 4/5 Pro utilizes a 12-bit ADC (4,096 discrete steps), eliminating micro-staircase snapping inside sub-2% micro-adjustments.
Response Curve & Deadzone Engine
Linear (y = x)
Vader 5 Pro Recommended Presets
Inner Deadzone (Hardware/Software Null-Zone)
3.0% (123 / 4096)
Outer Deadzone (Max Saturation Threshold)
98.0% (4014 / 4096)
Curve Exponent / Acceleration Curve (Gamma)
1.45 (Dynamic S-Curve)
Anti-Deadzone Compensation (Game Engine Override)
0.0%
ADC Resolution Comparison
MICRO-AIM LADDER
12-BIT (Vader 5 Pro: 4096 steps)
4096 / 4096
10-BIT (Standard Hall Effect: 1024 steps)
1024 / 1024
8-BIT (Legacy Potentiometer: 256 steps)
256 / 256
Real-Time Math Telemetry
| Raw Magnitude (r_in) | 0.0000 |
|---|---|
| Effective Deadzone Gate | Active (0.00) |
| Normalized Travel (t) | 0.0000 |
| Shaped Curve Power | 1.450 |
| 12-Bit Quantized Delta | 0.024% (1 step) |
| Circularity Deviation | 0.32% Avg |
Flydigi Space Station JSON
