Vessel Draft & Hydrostatic Cargo Planner | MSC IRENE Vizhinjam Case

Discharged Cargo Delta

92,400 MT

Δ Draft: 5.60 m (15.20m → 9.60m)

Discharged Container Volume

7,700 TEU

@ 12.00 MT / TEU average

Ballast Water Intake Required

36,960 MT

Trim & Hydrostatic Compensation (40%)

Vizhinjam UKC Margin

4.80 m

20.0m Natural Depth vs 15.2m Draft

Operational Inputs MSC Megamax 24k

Operational Profile Presets

Arrival Draft (T_arr) 15.20 m

Departure Draft (T_dep) 9.60 m

Seawater Density (ρ) 1.025 g/cm³

1.000 (Fresh) 1.025 (Marine Std)

Avg Cargo Weight / TEU 12.0 MT

Port Berth Bathymetry Depth

Transit Speed (Corridor) 18.0 knots

Static Operational State

Dynamic Hull Hydrostatic & Bathymetry Profile

MSC IRENE (Megamax 24k TEU)

Draft vs. Displacement Hydrostatics Curve

Hydrostatic Operational Breakdown

Parameter	Arrival State	Departure State	Delta / Impact

Port Call & Route Logistics Assessment

Vizhinjam Advantage: Natural 20m depth eliminates lightering requirements for 15.2m deep-draft megamax vessels, saving ~2.4 days port turnaround.

Stability & Ballast Protocol: 36,960 MT sea water intake necessary to compensate for 92,400 MT container discharge and maintain metacentric height (GM).

Hydrodynamic Fuel Efficiency: Draft reduction from 15.2m to 9.6m reduces wetted surface area, cutting corridor drag power demand by ~21.4%.
