PHYSICS 1865 • VILLARI EFFECT

Villari Magnetoelastic Energy Harvester

2D Magnetoelastic Beam & Microscopic Domain Lattice HARVESTING KINETIC STRAIN
Drag ribbon to deform manually
• Cyan arrows: Magnetic domains ($\mathbf{M}$)  • Amber/Red: Tensile/Compressive Stress ($\sigma$)  • Coil: Faraday Pickup
Mechanical Strain ($\epsilon$)
3.80 %
Applied Stress ($\sigma$)
42.5 MPa
Magnetic Flux Rate ($d\Phi/dt$)
18.4 Wb/s
Induced Voltage ($V_{emf}$)
46.2 mV
Instantaneous Power
2.13 mW
Harvested Storage
342.5 μJ
Oscilloscope: Real-time $\sigma(t)$ vs Induced $V(t)$
500 FPS SAMPLER
Harvested Micro-Grid Load
LED Circuit: Illuminating from kinetic flux
Capacitor Charge

The 1865 Villari Discovery

Italian physicist Emilio Villari discovered that applying mechanical stress to ferromagnetic materials alters their magnetic susceptibility and domain structure (the inverse of James Joule's magnetostriction effect).

Stress-to-Induction Physics

Tensile stress ($\sigma > 0$) aligns domains along the strain axis in positive magnetoelastic materials like Galfenol ($\text{Fe}_{81.6}\text{Ga}_{18.4}$), whereas compressive stress ($\sigma < 0$) forces transverse alignment, modulating net flux $\Phi(t)$ through the pickup coil.

Ambient Energy Applications

Unlike fragile piezoelectric ceramics, flexible magnetoelastic alloys can harvest turbulent ambient energy from fluttering tent fabrics, walking footwear insoles, and marine wave surfaces without mechanical fatigue.
