Kinetic Diorama Select
3-in-1 Base
Internal Kinematics
2,880 Bricks
Mech Advantage
3.0 : 1
Cam Stroke
14.0 mm
Clutch Tension
92 cN·m
Kinetic Efficiency
96.4%
| STAGE LINKAGE | TYPE | PITCH/TEETH |
|---|---|---|
| Motor Pinion | Spur Gear | 12T (Brass) |
| Idler Reducer | Compound | 36T / 12T |
| Output Crown | Bevel Gear | 24T (Emerald) |
| Linear Lifter | Rack & Pinion | 14mm Stroke |
Orbital Ring Ascent: Controller trigger RT applies drive torque through 3:1 planetary spur train to spin the ring halo, while button (A) actuates linear rack hoist.
