Airplane Window Bleed Hole Simulator

OUTSIDE ATMOSPHERE INTER-PANE CAVITY PASSENGER CABIN

Cruising Altitude 35,000 ft (10,668 m)

Nominal Cruise Physics: The bleed hole in the middle pane lets cabin air gently pressurize the inter-pane cavity to 11.80 PSI. This routes 100% of the cabin pressure differential (8.34 PSI) onto the thick outer acrylic structural pane, keeping the middle pane stress-free while venting moisture to prevent window fog and frost.

Flight Telemetry NOMINAL_SAFE

Ambient Pressure (Atm) 3.46 psi 35,000 ft

Cabin Pressure (Equiv) 11.80 psi ~8,000 ft cabin

Cavity Pressure 11.80 psi Equilibrated

Total Delta-P (ΔP) 8.34 psi 57.5 kPa

Pane Load Distribution STRESS MAP

1. Outer Structural Pane (12mm) 8.34 PSI LOAD

2. Middle Fail-Safe Pane (8mm) 0.00 PSI (SAFE)

3. Inner Scratch Shield (4mm) 0.00 PSI (PROTECT)
