Deep Pressure Submersible Hull Stress Simulator

DEPTH: 3,800 m

PRESSURE: 38.0 MPa (380 bar)

HOOP STRESS: 209.5 MPa

STATUS: SAFE

Ocean Depth 3,800 m

Titanic wreck sits at ~3,800m depth

Hull Material

Wall Thickness (t) 127 mm

Hull Outer Radius (r) 0.70 m

Asymmetry / Out-of-Roundness 2.0 %

Geometric imperfections dramatically accelerate buckling

Critical Buckling P: 31.2 MPa

Yield Safety Factor: 3.82

Buckling Safety Factor: 0.82

Structural FEA & Hydrostatic Failure Analysis Report
