Irrigation Pipe Acoustic Leak & Resonance Analyzer

System Presets

Hydraulic & Pipe Parameters

Pipe Material

Pipe Length (L) 50 m

Pipe Inner Diameter (D) 25 mm

Pressure Head (P) 200 kPa

Emitter Count 20 units

Pinhole Leak Anomaly

Leak Location (X_leak) 18.5 m

Leak Orifice Diameter 1.5 mm

Hydro-Acoustic Sensor Probe 18.5 m

Water Loss Rate

48.6 L/hr

Unintended Leakage

Flow Efficiency

88.4%

Useful / Total Flow

Acoustic Peak Freq

425 Hz

Resonance Mode #5

Turbulent Hiss Level

-14.2 dB

Probe Signal Power

Pipeline Schematic & Pressure Standing Wave

Drag yellow sensor pin or slider along pipe

Water Inlet (0m) Leak Pin (18.5m) Probe Pipe End (50m)

Acoustic Spectrum Analyzer (FFT) & Harmonics

Probe directly on leak anomaly

Resonance Peak Harmonics (f₁ - f₅):

85 Hz 170 Hz 255 Hz 340 Hz 425 Hz ★

Acoustic Inspection Diagnostic Proof

Hydraulic & Spectrum State Sync

At 200 kPa pressure head across a 50m HDPE pipe with 20 drip emitters, a 1.5mm orifice leak at 18.5m generates a dominant turbulent acoustic noise peak at 425 Hz (-14.2 dB signal power at probe). Unintended water loss is 48.6 L/hr, resulting in 88.4% flow efficiency.
