iPhone Pro Case Spec Lab

Interactive 3D geometry engine, micro-clearance lay-flat gauge, drop impact deceleration calculator, and MagSafe magnetic flux auditor.

Geometry & Materials

Custom Spec

Backplate Thickness 1.6 mm

Screen Lip Bevel (Z-offset) 1.3 mm

Height above display glass. Requires ≥0.4mm for glass protector clearance.

Camera Island Plateau Rim 1.8 mm

Bezel standoff safeguarding sapphire lens element array.

Corner Impact Cushion 2.4 mm

Material & Magnetics

Composite Substrate

MagSafe Ring Magnetic Grade

Impact Test Simulation

Drop Velocity Rig Height 1.8 m (6.0 ft)

Drop Vector Angle

Spatial Fit & Impact Inspection

Real-Time Kinematic & Stress Analysis

SIM READY • ORBIT DRAG ACTIVE

Screen Lay-Flat Margin +1.30 mm ✓ Safe Lay-Flat

Camera Island Standoff +1.80 mm ✓ Lens Shielded

Peak Impact Shock 38.2 G ✓ Chassis Dampened

MagSafe Holding Force 14.6 N ✓ Car Mount Safe

Precision Tolerances & Glass Protection Gauges

MIL-STD-810H & Qi2 Reference

Front Display Glass Lip Standoff 1.30 mm

Elevated bevel keeps touchscreen 1.30mm above flat contact planes.

MagSafe Magnetic Shear Coupling 14.6 N (1.49 kg-f)

Optimal magnetic flux retention through composite backplate.

All clearances pass MIL-STD-810H 6-foot drop parameters. Ready for specification export.

Lay-Flat Bevel Mechanics

A bare phone resting on a table exposes its micro-textured display glass and sapphire camera lenses to abrasive quartz sand dust. A minimum 0.8mm screen lip ensures tempered glass screen protectors remain safely ungrounded.

Corner Deceleration (G-Forces)

In 45-degree corner drops, deceleration without air pockets can spike beyond 150 G, transmitting fracture shear to internal logic board solder balls. Elastic TPU bumpers dissipate kinetic energy over an extended crush distance.

MagSafe Flux Attenuation

Magnetic field strength decays with the inverse square of distance. Every additional 0.5mm of backplate resin decreases magnetic retention by ~18% unless augmented by an integrated co-molded Neodymium magnet array.
