Terafab Scale Visualizer & Megafab Simulator

Comparative Overlay Footprints

Terafab (100M sq ft) Tesla Giga Texas (10M sq ft) Boeing Everett (4.3M sq ft) The Pentagon (6.5M sq ft) Central Park, NYC (84M sq ft)

1. Spatial Metrics

Footprint (Sq Meters)

9,290,304

9.29 sq kilometers

Football Fields

1,730

Std US NFL Fields

Perimeter Walk Duration

2 hrs 45 mins

13.8 km continuous walk perimeter

Cleanroom Allocation (% of Facility) 35%

Target Monthly Wafer Starts (WPM) 250,000

Lithography Scanner Density (EUV Suites) 80 Suites

Class 1/100 Cleanroom

35.0M sq ft

Annual 300mm Wafers

3.00M

Rooftop Solar Coverage 80%

Peak Power Draw

1.20 GW

1,200 MW Grid Draw

Solar Roof Generation

1,450 GWh/yr

~13.8% Total Fab Demand

Terafab Texas 100M sq ft (1.0x)

Tesla Giga Texas 10M sq ft (10x smaller)

The Pentagon 6.5M sq ft (15x smaller)

Boeing Everett Factory 4.3M sq ft (23x smaller)
