Human Tissue Electrical Energy Dissipation Simulator

Potential Relaxation: 100% (Converged) Pulse State: IDLE

Peak Voltage (kV) 1.20 kV

Pulse Duration (ms) 50 ms

Contact Area (cm²) 4.0 cm²

Skin Moisture State

Tissue Bio-Thermal Proof & Diagnostics

Peak Current Density

1845.2 A/m²

Peak Joule Heating

328.4 W/cm³

Max Temperature Rise

24.6 °C

Arrhenius Damage Index

0.82 (Reversible)

Dominant Dissipation Layer

Muscle

Max Current Density 1845.2 A/m² (Peak Local Vector)

Max Joule Heating 328.4 W/cm³ (Power Dissipation)

Max Temp Rise 24.60 °C (Bio-Thermal Load)

Arrhenius Damage Ω 0.82 Cumulative Burn Risk

Thermal Transient ΔT(t) Pulse Transient

Layer Energy Breakdown Total Thermalized Joules

Biological Tissue Strata Electrical Properties

Epidermis (Outer Skin)

σ = 0.0005 S/m

Dermis

σ = 0.20 S/m

Subcutaneous Fat

σ = 0.04 S/m

Skeletal Muscle

σ = 0.50 S/m

Bone

σ = 0.02 S/m
