Young's Modulus Lab

E = σ / ε
Test Controls TENSILE UTM

Drag crosshead directly on canvas or use slider to pull / compress.

Engineering Presets
Stress (σ)
0.0MPa
Strain (ε)
0.000mm/mm
Young's Modulus (E)
200.0GPa
Material Phase
Elastic (Hooke's)
Material Properties
Young's Modulus (E) 200 GPa
Yield Strength (σ_y) 250 MPa
Ultimate Tensile (σ_u) 400 MPa
Fracture Strain (ε_f) 0.250 mm/mm
Density (ρ) 7,850 kg/m³
Lab Observations
Linear elastic region: Stress is directly proportional to strain (Hooke's Law: σ = E · ε). Releasing the load now allows full elastic recovery.
Active Test State: Structural Steel (A36) @ 0.000 strain.
