Noyce Planar IC Workbench

US Patent 2,981,877 (July 30, 1959)
Preset Layout:
Architecture:
STEP 1 SiO2 Oxidation
STEP 2 Photoresist / Mask
STEP 3 Acid Etch
STEP 4 N+ Doping
STEP 5 Planar Metallization
Historical Invention Insight: Jack Kilby (1958) created the first solid circuit, but relied on fragile hand-soldered flying gold wires. Robert Noyce (July 30, 1959) solved the "tyranny of numbers" by thermal-growing silicon dioxide (SiO2) insulation and photo-etching aluminum conductor tracks directly across the planar chip surface. Drag on the canvas to route planar aluminum metallization traces!
âš¡ Stress & Mechanical Vibration Stable
25 G
300 nm
5.0 µm
📊 Extracted Parasitic Physics
Trace Resistance ($R_{trace}$)
1.40 Ω
Oxide Cap ($C_{oxide}$)
0.23 pF
RC Delay ($\tau = R \cdot C$)
0.32 ps
Max Bandwidth ($f_{max}$)
497 GHz
Structural Yield ($Y_{mech}$)
99.8 %
Wire Stray $L$
0.02 nH
TRANSIENT WAVEFORM (INPUT vs OUTPUT NODE)
🔬 Monolithic Proof Summary
Active Circuit: planar_rtl_nor_gate
Architecture: Noyce Planar Aluminum
Interconnect State: Monolithic Integrated Pass
